型号

分辨率（mm）

光轴数

保护高度（mm）

总长度（mm）

LS4T-14-0150W

14

16

150

166

LS4T-14-0170W

14

18

170

186

LS4T-14-0190W

14

20

190

206

LS4T-14-0210W

14

22

210

226

LS4T-14-0230W

14

24

230

246

LS4T-14-0250W

14

26

250

266

LS4T-14-0270W

14

28

270

286

LS4T-14-0290W

14

30

290

306

LS4T-14-0310W

14

32

310

326

LS4T-14-0330W

14

34

330

346

LS4T-14-0350W

14

36

350

366

LS4T-14-0370W

14

38

370

386

LS4T-14-0390W

14

40

390

406

LS4T-14-0410W

14

42

410

426

LS4T-14-0430W

14

44

430

446

LS4T-14-0450W

14

46

450

466

LS4T-14-0470W

14

48

470

486

LS4T-14-0490W

14

50

490

506

LS4T-14-0510W

14

52

510

526

LS4T-14-0530W

14

54

530

546

LS4T-14-0550W

14

56

550

566

LS4T-14-0570W

14

58

570

586

LS4T-14-0590W

14

60

590

606

LS4T-14-0610W

14

62

610

626

LS4T-14-0630W

14

64

630

646

LS4T-14-0650W

14

66

650

666

LS4T-14-0670W

14

68

670

686

LS4T-14-0690W

14

70

690

706

LS4T-14-0710W

14

72

710

726

LS4T-14-0730W

14

74

730

746

LS4T-14-0750W

14

76

750

766

LS4T-14-0770W

14

78

770

786

LS4T-14-0790W

14

80

790

806

LS4T-14-0810W

14

82

810

826

LS4T-14-0830W

14

84

830

846

LS4T-14-0850W

14

86

850

866

LS4T-14-0870W

14

88

870

886

LS4T-14-0890W

14

90

890

906

LS4T-14-0910W

14

92

910

926

LS4T-14-0930W

14

94

930

946

LS4T-14-0950W

14

96

950

966

LS4T-14-0970W

14

98

970

986

LS4T-14-0990W

14

100

990

1006

LS4T-14-1010W

14

102

1010

1026

LS4T-14-1030W

14

104

1030

1046

LS4T-14-1050W

14

106

1050

1066

LS4T-14-1070W

14

108

1070

1086

LS4T-14-1090W

14

110

1090

1106

LS4T-14-1110W

14

112

1110

1126

LS4T-14-1130W

14

114

1130

1146

LS4T-14-1150W

14

116

1150

1166

LS4T-14-1170W

14

118

1170

1186

LS4T-14-1190W

14

120

1190

1206

LS4T-14-1210W

14

122

1210

1226

LS4T-14-1230W

14

124

1230

1246

LS4T-14-1250W

14

126

1250

1266

LS4T-14-1270W

14

128

1270

1286

LS4T-14-1290W

14

130

1290

1306

LS4T-14-1310W

14

132

1310

1326

LS4T-14-1330W

14

134

1330

1346

LS4T-14-1350W

14

136

1350

1366

LS4T-14-1370W

14

138

1370

1386

LS4T-14-1390W

14

140

1390

1406

LS4T-14-1410W

14

142

1410

1426

LS4T-14-1430W

14

144

1430

1446

LS4T-14-1450W

14

146

1450

1466

LS4T-14-1470W

14

148

1470

1486

LS4T-14-1490W

14

150

1490

1506

LS4T-14-1510W

14

152

1510

1526

LS4T-14-1530W

14

154

1530

1546

LS4T-14-1550W

14

156

1550

1566

LS4T-14-1570W

14

158

1570

1586

LS4T-14-1590W

14

160

1590

1606

LS4T-14-1610W

14

162

1610

1626

LS4T-14-1630W

14

164

1630

1646

LS4T-14-1650W

14

166

1650

1666

LS4T-14-1670W

14

168

1670

1686

型号

分辨率（mm）

光轴数

保护高度（mm）

总长度（mm）

LS4T-25-0140W

25

8

140

166

LS4T-25-0180W

25

10

180

206

LS4T-25-0220W

25

12

220

246

LS4T-25-0260W

25

14

260

286

LS4T-25-0300W

25

16

300

326

LS4T-25-0340W

25

18

340

366

LS4T-25-0380W

25

20

380

406

LS4T-25-0420W

25

22

420

446

LS4T-25-0460W

25

24

460

486

LS4T-25-0500W

25

26

500

526

LS4T-25-0540W

25

28

540

566

LS4T-25-0580W

25

30

580

606

LS4T-25-0620W

25

32

620

646

LS4T-25-0660W

25

34

660

686

LS4T-25-0700W

25

36

700

726

LS4T-25-0740W

25

38

740

766

LS4T-25-0780W

25

40

780

806

LS4T-25-0820W

25

42

820

846

LS4T-25-0860W

25

44

860

886

LS4T-25-0900W

25

46

900

926

LS4T-25-0940W

25

48

940

966

LS4T-25-0980W

25

50

980

1006

LS4T-25-1020W

25

52

1020

1046

LS4T-25-1060W

25

54

1060

1086

LS4T-25-1100W

25

56

1100

1126

LS4T-25-1140W

25

58

1140

1166

LS4T-25-1180W

25

60

1180

1206

LS4T-25-1220W

25

62

1220

1246

LS4T-25-1260W

25

64

1260

1286

LS4T-25-1300W

25

66

1300

1326

LS4T-25-1340W

25

68

1340

1366

LS4T-25-1380W

25

70

1380

1406

LS4T-25-1420W

25

72

1420

1446

LS4T-25-1460W

25

74

1460

1486

LS4T-25-1500W

25

76

1500

1526

LS4T-25-1540W

25

78

1540

1566

LS4T-25-1580W

25

80

1580

1606

LS4T-25-1620W

25

82

1620

1646

LS4T-25-1660W

25

84

1660

1686

LS4T-25-1700W

25

86

1700

1726

LS4T-25-1740W

25

88

1740

1766

LS4T-25-1780W

25

90

1780

1806

LS4T-25-1820W

25

92

1820

1846

LS4T-25-1860W

25

94

1860

1886

LS4T-25-1900W

25

96

1900

1926

LS4T-25-1940W

25

98

1940

1966

LS4T-25-1980W

25

100

1980

2006

LS4T-25-2020W

25

102

2020

2046

LS4T-25-2060W

25

104

2060

2086

LS4T-25-2100W

25

106

2100

2126

LS4T-25-2140W

25

108

2140

2166

LS4T-25-2180W

25

110

2180

2206

LS4T-25-2220W

25

112

2220

2246

LS4T-25-2260W

25

114

2260

2286

LS4T-25-2300W

25

116

2300

2326

LS4T-25-2340W

25

118

2340

2366

LS4T-25-2380W

25

120

2380

2406

LS4T-25-2420W

25

122

2420

2446

LS4T-25-2460W

25

124

2460

2486

型号

分辨率（mm）

光轴数

保护高度（mm）

总长度（mm）

LS4T-45-0120W

45

4

120

166

LS4T-45-0200W

45

6

200

246

LS4T-45-0280W

45

8

280

326

LS4T-45-0360W

45

10

360

406

LS4T-45-0440W

45

12

440

486

LS4T-45-0520W

45

14

520

566

LS4T-45-0600W

45

16

600

646

LS4T-45-0680W

45

18

680

726

LS4T-45-0760W

45

20

760

806

LS4T-45-0840W

45

22

840

886

LS4T-45-0920W

45

24

920

966

LS4T-45-1000W

45

26

1000

1046

LS4T-45-1080W

45

28

1080

1126

LS4T-45-1160W

45

30

1160

1206

LS4T-45-1240W

45

32

1240

1286

LS4T-45-1320W

45

34

1320

1366

LS4T-45-1400W

45

36

1400

1446

LS4T-45-1480W

45

38

1480

1526

LS4T-45-1560W

45

40

1560

1606

LS4T-45-1640W

45

42

1640

1686

LS4T-45-1720W

45

44

1720

1766

LS4T-45-1800W

45

46

1800

1846

LS4T-45-1880W

45

48

1880

1926

LS4T-45-1960W

45

50

1960

2006

LS4T-45-2040W

45

52

2040

2086

LS4T-45-2120W

45

54

2120

2166

LS4T-45-2200W

45

56

2200

2246

LS4T-45-2280W

45

58

2280

2326

LS4T-45-2360W

45

60

2360

2406

LS4T-45-2440W

45

62

2440

2486

欧洲标准

EN 61496-1、2:2020、EN 61508-1~4:2020、EN ISO 13849-1、2:2023

国际标准

IEC 61496-1、2:2020、IEC61508-1~4:2010、ISO 13849-1、2:2023

安全类别

安全等级

Type4 Category 4 PLe

DCavg

99%

CCF

100

光学特性

光轴间距

10mm/20mm/40mm

分辨率

14mm/25mm/45mm

光轴数量

4、6、8、10…256

保护高息

光轴间距×（光轴数量-1）

保护宽度

0.2m-5m

截面尺寸

30mm×30mm（无盲区）

电气特性

电源电压

24V±10%

功率

3～8W

响应时间

≤10ms

绝缘电阻

≥100MΩ

信号输出

NPN、PNP

工作温度

- 0℃~+55℃

储存温度

-40℃~+70℃

工作湿度

35%RH~85% RH

抗光干扰

10000LUX

光幕形式

对射型

防护等级

IP65/IP67

产品认证

CE TUV

电路保护

反接保护/输出短路保护，双路电路控制系统，自我诊断进行故障检查，更高级别冗余故障互检等

可配控制器

是
